Driven pulley

DRIVEN PULLEY - CLUTCH

Code

Action Duration

1 001110 Driven pulley - Replacement

2 001012 Driven pulley - Overhaul

3 001022 Clutch - Replacement

4 001155 Clutch bell housing - Replacement

Time MSS ZIP 100 4T

TIME - 160
