34
Connecting your equipment
03
Connecting your TV and playback components
Connecting using HDMI
If you have an HDMI or DVI (with HDCP) equipped component (Blu-ray Disc player (BD), etc.), you can connect it
to this receiver using a commercially available HDMI cable.
If the TV and playback components support the Control with HDMI feature, the convenient Control with HDMI
functions can be used (see Control with HDMI function on page 74 ).
LAN
(
10/100
)
DC OUTPUT
for WIRELESS LAN
(
OUTPUT 5 V
0.6 A MAX
)
(
OUTPUT 5 V
0.9 A MAX
)
OPTICALCOAXIAL
ASSIGNABLEASSIGNABLE
IN
1
(
CD
)
IN
1
(
DVD
)
BD IN
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
6
IN
4
IN
7
/MHL
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
OUT
OUT 3
(HDZONE)
OUT 2OUT 1
(CONTROL)
SELECTABLE
HDMI
ASSIGNABLE
1
-
7
ASSIGN-
ABLE
IN
1
(
CD
)
ASSIGN-
ABLE
LAN
(
10/100
)
DC OUTPUT
for WIRELESS LAN
(
OUTPUT 5 V
0.6 A MAX
)
(
OUTPUT 5 V
0.9 A MAX
)
OPTICALCOAXIAL
ASSIGNABLE ASSIGNABLE
IN
1
(
DVD
)
BD IN
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
6
IN
4
IN
7
/MHL
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
OUT
OUT 3
(HDZONE)
OUT 2OUT 1
(CONTROL)
SELECTABLE
HDMI
ASSIGNABLE
1
-
7
DIGITAL OUT
COAXIAL OPTICAL
ANALOG
RL
AUDIO OUT
HDMI IN
HDMI OUT HDMI OUT
HDMI/DVI-compatible
Blu-ray Disc player
Other HDMI/DVI-
equipped component
HDMI/DVI-compatible
monitor
Select one
This connection is required in
order to listen to the sound of
the TV over the receiver.
! When connecting to an HDMI/DVI-compatible monitor using the HDMI OUT 2 terminal, switch the HDMI
output setting to OUT 2 or OUT 1+2. See Switching the HDMI output on page 84 .
In the same way, when an HDMI/DVI-compatible monitor is connected to the HDMI OUT 3 terminal, switch
the HDMI OUT 3 setting to ON (page 84 ). In this case, MAIN/HDZONE at ZONE Setup must be set to MAIN
(page 109 ).
! For input components, connections other than HDMI connections are also possible (see Connecting your DVD
player with no HDMI output on page 35 ).
! If you want to listen to the sound of the TV over the receiver, connect the receiver and TV with audio cables.
— When the TV and receiver are connected by HDMI connections, if the TV supports the HDMI ARC (Audio
Return Channel) function, the sound of the TV can be input to the receiver via the HDMI OUT terminal, so
there is no need to connect an audio cable. In this case, set ARC at HDMI Setup to ON (see HDMI Setup on
page 75 ).
After setting the ARC, some time may be required for the connected device to be recognized and the sound to
be produced.
— If you use a coaxial digital audio cable or RCA (analog) audio cable, you’ll need to tell the receiver which digi-
tal or analog audio input you connected the TV to (see The Input Setup menu on page 52 ).
— Please refer to the TV’s operation manual for directions on connections and setup for the TV.
! If the TV to be connected using HDMI supports 4K/60p, you can switch the 4K/60p signal output setting in
accordance with TV performance. When the 4K/60p setting is changed to 4:4:4, the video image may not be
output normally unless the HDMI cable supports 4K/60p 4:4:4 24 bit (18 Gbps transmission). In such a case,
select 4:2:0 (page 84 ).
! You cannot input 4K/60p 4:4:4 24 bit video from HDMI IN 3 to the IN 7 terminal. Use the BD IN, HDMI IN 1 or
HDMI IN 2 terminal.
! The HDMI OUT 3 terminal outputs 4K/60p 4:4:4 24 bit video when MAIN/HDZONE is set to MAIN. When it is
set to HDZONE, the 4K/60p 4:4:4 24 bit video is not output.
To Next Page
