Chapter 3 Hardware Configuration
SE-8134 SERIES USER MANUAL
Page: 3-2
3.1 JUMPER & CONNECTOR QUICK REFERENCE TABLE
JUMPER Description
NAME
AT / ATX Mode Selection
JP_ATX1
COM1 RI/5V/12V Selection
JP_COM1
COM2 Pin9 RI/5V/12V Selection
JP_COM2
I2C PIN2 Voltage Selection
JP_I2C1
TPM Module Selection
JP_TPM1
Clear CMOS Data Selection
JP4
HDMI2 Selection
JP_EDP1, JP8
System CONNECTOR Description
NAME
Rear I/O Port Connectors
COM Port Connectors
COM1, COM2
LAN1, LAN2 Ports
LAN1, LAN2
Dual USB 3.0 Connectors
USB1
USB 3.0 Connector
USB2
HDMI Connector
HDMI1
DVI (Digital Visual Interface) Connector
DVI1
HD Audio Connector
AUDIO1
Power Input Connector
CN_POWER1
Front I/O Port Connectors
COM Port Connectors
COM3, COM4
USB 3.0 Connector
USB3
Digital Input/ Output Connectors
DIO1
HDMI Connector
HDMI2
Mainboard Top Side Connectors
Power Button Connector
J_PBTN1
Digital Input/ Output Connectors
JDIO1
Mini PCI Express Slot
M_PCIE1
Mini-Serial ATA (SATA) Slot
mSATA1
SATA 3.0 Connectors
SATA1
HDD Power Connector
SATA_PWR1
I2C Wafer
JI2C1, JI2C2
Low Pin Count (LPC) Connector
JLPC1
Power over Ethernet (PoE) Connector
JPOE1
