Configuration
The Engineer Menu
The system is programmed from the Engineer Menu. To enter the Engineer Menu, the panel must be
in fully disarmed state. Whilst in Engineer Mode, all tamper alarms (excluding PA and safety devices)
will be disabled.
Navigating in the Engineer and User Menus
x
NO Press to move forward when in Engineer or Master Manger mode.
b
BACK Press to move backward when in Engineer or Master Manger mode.
t
YES Press to enter in a submenu or option when in Engineer or Master Manger mode.
Press to move from one option into another option while in a submenu.
a
EXIT Press to quick exit the Engineer Menu from any main menu (written in capital letters).
c
CANCEL Press to move back from one programmable option to the previous option.
Main Menus and Sub Menus
You are in a main menu item if:
• The maintenance LED is flashing slowly
• The menu item will be in upper case letters with a
question mark (?).
You are in a sub menu item if:
• The maintenance LED is
flashing rapidly
• The menu item will be in lower
case letters.
In order to navigate in the menu system, one has to answer the questions in the main and sub menus.
For example, if the question is LEARN WIRELESS DEVICE?:
• Pressing t will bring you in the sub-menu Learn Inputs?
• Pressing t again will take you to the programmable options of this submenu.
• Pressing x will take you out of the individual option, will move you up from one submenu to the
next sub-menu or back to the main menu.
PCX Installation Guide 102017852 - V01 33
