5–Preboot Adapter Configuration
Data Center Bridging Configuration
45 BC0154503-00 C
Data Center Bridging Configuration
The data center bridging settings comprise the DCBX protocol and the remote
direct memory access (RDMA) over converged Ethernet (RoCE) priority.
To configure the data center bridging (DCB) settings:
1. Select Data Center Bridging (DCB) Settings in the Main Configuration
Page (Figure 5-1), and then click Finish.
2. In the Data Center Bridging (DCB) Settings page, click the DCBX Protocol
drop-down, and choose from the following options:
Disabled: Disables DCB
IEEE: IEEE protocol
CEE: Converged Enhanced Ethernet (CEE) protocol
Dynamic: Dynamically applies CEE or IEEE to match the attached link
partner
3. In the Data Center Bridging (DCB) Settings window, click the RoCE Priority
field, and then a type a value from 0–7.
4. Click Back.
5. When prompted, click Yes to save the changes. Changes will take effect
after a system reset.
