Icon
Icon Color
Status Description
White Video signal lost
Yellow View tampering alarm
Pink Motion&External alarm
Green No alarm
Blue Motion alarm
Red External alarm
Press numeric keys to switch over individual camera preview. If DVR has
less than 10 channels, press one numeric key to switch corresponding
channel. For example, press [2] key to preview 2
nd
camera. If DVR has
10 or more than 10 channels, press two numeric keys to switch
corresponding channel. For example, press [0] [2] to preview 2
nd
camera; and press [1] [2] keys to preview 12
th
camera.
Press [EDIT] key to manual cycle preview. You can set the auto preview
mode in “Preview” menu, referring to 5.11.
Press [PREV] key to switch multi-screen preview.
