Quectel EC21 Series User Manual

LTE Standard Module Series
EC21_Series_Hardware_Design
87
/ 118
5.2. Power Supply Ratings
Table 43: Power Supply Ratings
Parameter Description Conditions Min. Typ. Max. Unit
VBAT
VBAT_BB and VBAT_RF
The actual input voltages
must be kept between the
minimum and maximum
values.
3.3 3.8 4.3 V
Voltage drop during burst
transmission
Maximum power control
level on EGSM900
- - 400 mV
I
VBAT
Peak supply current
(during transmission slot)
Maximum power control
level on EGSM900
- 1.8 2.0 A
USB_VBUS USB connection detection - 3.0 5.0 5.25 V
5.3. Operating and Storage Temperatures
The operating and storage temperatures are listed in the following table.
Table 44: Operating and Storage Temperatures
Parameter Min. Typ. Max. Unit
Operating Temperature Range
10
-35 +25 +75 ºC
Extended Temperature Range
11
-40 - +85 ºC
Storage Temperature Range -40 - +90 ºC
10
Within operation temperature range, the module is 3GPP compliant.
11
Within extended temperature range, the module remains the ability to establish and maintain a voice, SMS, data
transmission, emergency call*, etc. There is no unrecoverable malfunction. There are also no effects on radio spectrum
and no harm to radio network. Only one or more parameters like P
out
might reduce in their value and exceed the specified
tolerances. When the temperature returns to the normal operation temperature levels, the module will meet 3GPP
specifications again.
