LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 12 / 69
be clearly visible at all times when installed in the host product; otherwise, the host product must be
labeled to display the Innovation, Science and Economic Development Canada certification number for
the module, preceded by the word “Contains” or similar wording expressing the same meaning, as follows:
“Contains IC: 10224A-2021EM05G” or “where: 10224A-2021EM05G is the module’s certification number”.
The host product must be properly labeled to identify the modules in the host product. The Innovation,
Science and Economic Development Canada certification label for a module must be clearly visible at all
times when it is installed in the host product; otherwise, the host product must be labeled with the
Innovation, Science and Economic Development Canada certification number for the module, preceded
by the word “Contains” or similar wording with the same meaning, as follows: "Contains IC:
10224A-2021EM05G" or "where: 10224A-2021EM05G is the certification number of the module".
1.1. Reference Standard
The module complies with the following standards:
⚫ PCI Express M.2 Specification Revision 3.0, Version 1.2
⚫ PCI Express Base Specification Revision 3.0
⚫ Universal Serial Bus 3.1 Specification
⚫ ISO/IEC 7816-3
⚫ MIPI Alliance Specification for RF Front-End Control Interface Version 2.0
⚫ 3GPP TS 27.007 and 3GPP TS 27.005
1.2. Special Marks
Table 1: Special Marks
When an asterisk (*) is used after a function, feature, interface, pin name, AT command, or
argument, it indicates that the function, feature, interface, pin name, AT command, or
argument is under development and currently not supported, unless otherwise specified.
Brackets ([…]) used after a pin enclosing a range of numbers indicate all pins of the same
type. For example, ANTCTL[0:3] refers to all four ANTCTL pins, ANTCTL0, ANTCTL1,
ANTCTL2 and ANTCTL3.
