Quectel EM05-G User Manual

LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 68 / 69
7.2. Top and Bottom Views of the Module
Figure 31: Top and Bottom View of the Module
Images above are for illustration purpose only and may differ from the actual module. For authentic
appearance and label, please refer to the module received from Quectel.
7.3. M.2 Connector
EM05-G adopts a standard PCI Express M.2 connector which compiles with the directives and standards
listed in document [1].
7.4. Packaging
EM05-G is packaged in tray. The following figure shows the tray size.
Figure 32: Tray Size (Unit: mm)
NOTE
