LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 50 / 69
5 RF Characteristics
5.1. Cellular Antenna Interfaces
EM05-G is mounted with three 2 × 2 mm antenna connectors for external antenna connection: a main
antenna connector, a Rx-diversity antenna connector, and a GNSS antenna connector. The impedance of
the antenna connectors is 50 Ω.
5.1.1. Connector Definition
Table 23: EM05-G Connector Definition of Antenna Interfaces
5.1.2. Operating Frequency
Table 24: Module Operating Frequencies
Antenna Pin Name
I/O
Description
Comment
ANT_MAIN
AIO
Main antenna interface:
LTE: TRx
WCDMA: TRx
50 Ω impedance
ANT_DRX/ANT_GNSS
AI
Rx-diversity/GNSS antenna interface:
LTE: DRx
WCDMA: DRx
GNSS: L1
50 Ω impedance
3GPP Band
Transmit
Receive
Unit
WCDMA B1
19201980
21102170
MHz
WCDMA B2
18501910
19301990
MHz
WCDMA B4
17101755
21102155
MHz
WCDMA B5
824849
869894
MHz
WCDMA B6
830840
875885
MHz
