Hardware
Design
EM05-G_Hard
ware_
Design
49
/
69
The follow
ing figure sh
ows
a reference c
ircuit f
or these f
our pins.
Host
Module
CONFIG_0
CONFIG_1
CONFIG_2
CONFIG_3
GPIO
GPIO
GPIO
GPIO
21
69
75
1
VCC_IO_HOST
R1
10k
R2
10k
R3
10k
R4
10k
0
Ω
NM-0
Ω
NM-0
Ω
0
Ω
Note:
The voltage level of VCC_IO_HOST depends on the host side and could be 1.8 V or 3.3 V.
Figure
24
:
Rec
ommend
ed Circ
uit for Co
nfigurati
on Pins
49
51
