Quectel EM05-G User Manual

LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 14 / 69
2.2. Key Features
The following table describes the detailed features of EM05-G.
Table 3: Key Features of EM05-G
1)
GNSS function is optional.
Feature
Details
Function Interface
PCI Express M.2 Standard Interface
Power Supply
⚫ Supply voltage: 3.135–4.4 V
⚫ Typical supply voltage: 3.3 V
Transmitting Power
⚫ Class 3 (24 dBm +1.5/-3 dB) for WCDMA bands
⚫ Class 3 (24 dBm +1.5/-3 dB ) for LTE-FDD bands
⚫ Class 3 (24 dBm +1.5/-3 dB ) for LTE-TDD bands
LTE Features
⚫ Support up to non-CA Cat 4
⚫ Support 1.4/3/5/10/15/20 MHz RF bandwidth
⚫ Support MIMO in DL direction
⚫ FDD: Max. 150 Mbps (DL), Max. 50 Mbps (UL)
⚫ TDD: Max. 130 Mbps (DL), Max. 30 Mbps (UL)
UMTS Features
⚫ Support 3GPP Rel-8 DC-HSDPA, HSPA+, HSDPA, HSUPA and
WCDMA
⚫ Support QPSK, 16QAM and 64QAM modulation
⚫ Max. transmission data rates:
- DC-HSDPA: 42 Mbps (DL)
- HSUPA: 5.76 Mbps (UL)
- WCDMA: 384 kbps (DL), 384 kbps (UL)
Internet Protocol Features
⚫ Support Internet service protocols:
TCP/UDP/PPP/FTP/HTTP/NTP/PING/QMI/NITZ/CMUX/HTTPS/SMTP/
MMS/FTPS/SMTPS/SSL
⚫ Support PAP and CHAP protocols for PPP connection
SMS
⚫ Text and PDU mode
⚫ Point-to-point MO and MT
⚫ SMS cell broadcast
⚫ SMS storage: ME by default
NOTE
