Quectel EM05-G User Manual

LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 64 / 69
Table 35: (U)SIM 3.0V I/O Requirements
The maximum voltage value of V
IL
for RESET# and W_DISABLE1# is 0.5 V.
6.4. Electrostatics Discharge
The module is not protected against electrostatic discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
application that incorporates the module.
The following table shows the ESD characteristics of EM05-G.
Table 36: ESD Characteristics of EM05-G (Temperature: 25 ºC , Humidity: 45 %)
For a good ESD performance, the module mounting holes must be used to attach the device to the main
PCB ground closely.
Parameter
Description
Min.
Max.
Unit
USIM_VDD
Power supply
2.7
3.05
V
V
IH
Input high voltage
0.7 × USIM_VDD
USIM_VDD + 0.3
V
V
IL
Input low voltage
-0.3
0.2 × USIM_VDD
V
V
OH
Output high voltage
0.8 × USIM_VDD
USIM_VDD
V
V
OL
Output low voltage
0
0.4
V
Tested Interfaces
Contact Discharge
Air Discharge
Unit
Power Supply and GND
±4
±10
kV
Antenna Interface
±4
±8
kV
Others
±0.5
±1
kV
NOTE
NOTE
