Quectel EM05-G User Manual

LTE Standard Module Series
EM05-G Hardware Design
EM05-G_Hardware_Design 53 / 69
LTE-FDD B25 (10 MHz)
TBD
TBD
-100.6 dBm
-92.8 dBm
LTE-FDD B26 (10 MHz)
TBD
TBD
-101.6 dBm
-93.8 dBm
LTE-FDD B28 (10 MHz)
TBD
TBD
-100.9 dBm
-94.8 dBm
LTE-TDD B38 (10 MHz)
TBD
TBD
-98.7 dBm
-96.3 dBm
LTE-TDD B39 (10 MHz)
TBD
TBD
-101 dBm
-96.3 dBm
LTE-TDD B40 (10 MHz)
TBD
TBD
-99.7 dBm
-96.3 dBm
LTE-TDD B41 (10 MHz)
TBD
TBD
-99 dBm
-94.3 dBm
LTE-FDD B66 (10 MHz)
TBD
TBD
-100.1 dBm
-95.8 dBm
LTE-FDD B71 (10 MHz)
TBD
TBD
-101.2 dBm
-93.5 dBm
5.1.4. RF Output Power
The following table shows the RF output power of EM05-G module.
Table 26: Conducted RF Output Power of EM05-G
Frequency Bands
Max. RF Output Power
Min. RF Output Power
LTE-FDD Bands
24 dBm ±2 dB
< -39 dBm
LTE-TDD Bands
24 dBm ±2 dB
< -39 dBm
WCDMA Bands
24 dBm +1/-3 dB
< -49 dBm
