Quectel Smart EVB G5 User Manual

Smart Module Series
Smart_EVB_G5_User_Guide 11 / 66
2 Product Overview
Key Features
Table 3: Key Features
Features
Implementation
Power supply
⚫ DC power supply: 5–36 V (typical: 5 V)
⚫ VBAT: 3.55–4.4 V (typical: 3.8 V)
LCM interfaces
⚫ Two 5-inch 1280 × 720 HD resolution LCDs
⚫ 4-lane MIPI DSI interface for each LCD
Touch panel interfaces
Two capacitive touch panels
Camera interfaces
Support three cameras:
⚫ Rear camera supports 16M pixels with 4-lane CSI interface
⚫ Front camera supports 8M pixels with 2-lane CSI interface
⚫ Depth camera supports 2M pixels with 1-lane CSI interface
USB interface
Support USB Type-C interface and Micro-USB interface:
⚫ Compliant with USB 3.0 and 2.0 specifications, with transmission
rates up to 5 Gbps on USB 3.0 and 480 Mbps on USB 2.0
⚫ Support USB OTG
⚫ Used for AT command communication, data transmission, software
debugging and firmware upgrade
Audio interfaces
Analog Inputs:
3 groups of analog microphone inputs, integrating internal bias voltage.
⚫ One headset input
⚫ One ECM-type microphone input
⚫ One MEMS-type microphone input
Analog Outputs:
3 groups of analog audio outputs, including:
⚫ One stereo headset output
⚫ One mono earphone differential output
⚫ One mono loudspeaker differential amplifier output
(U)SIM card interfaces
⚫ Support (U)SIM cards: 1.8 V and 2.95 V
⚫ Support dual SIM dual standby

Quectel Smart EVB G5 Specifications

General

Brand	Quectel
Model	Smart EVB G5
Category	Control Unit
Language	English
