Quectel Smart EVB G5 User Manual

Smart Module Series
Smart_EVB_G5_User_Guide 39 / 66
Table 13: Pin Definition of Touch Panel Interfaces
Camera Interfaces
Smart EVB G5 provides three camera interfaces (4-lane + 2-lane + 1-lane) with rear camera, front camera
and depth camera assembled.
Table 14: Description of Camera Interfaces
Pin No.
Pin Name
Description
1
TP_SDA
I2C data signal of touch panel
2
TP_SCL
I2C clock signal of touch panel
3
TP_RST
Reset signal of touch panel
4
TP_INT
Interrupt signal of touch panel
5
GND
Ground
6
VDD
2.8V power supply for touch panel VDD power
RefDes.
Description
J0401
Rear camera connector, support 16M CMOS sensor with auto-focusing function
J0402
Front camera connector, support 8M CMOS sensor with auto-focusing function
J0403
Depth camera connector, support 2M CMOS sensor with auto-focusing function
