Quectel Smart EVB G5 User Manual

Smart Module Series
Smart_EVB_G5_User_Guide 25 / 66
Table 7: Pin Definition of Battery Interface
Smart TE-A Interface
The Smart TE-A interface includes two B2B connectors J0101 and J0102. Smart TE-A is connected to the
EVB via the two connectors.
Table 8: Description of Smart TE-A Interface
Pin No.
Pin Name
Description
1, 2
GND
GND pins
Connected to the negative pole of the battery
3
THERM
Detect battery temperature
A 47K thermistor is used for the battery protection circuit
4
ID
Reserved
5, 6
VBAT
Power input pins
Connect to the positive pole of the battery
RefDes.
Description
J0101
Connectors for connecting Smart TE-A with Smart EVB G5
J0102
