Smart Module Series
Smart_EVB_G5_User_Guide 47 / 66
Figure 30: MEMS-Type and ECM-Type Microphones
(U)SIM Card Interfaces
The Smart EVB G5 provides two 6-pin push-push type (U)SIM card (1.8/2.95 V) connectors which support
1.8/2.95 V (U)SIM card.
Table 18: Description of (U)SIM Card Interfaces
RefDes.
Description
J1001
(U)SIM1 card connector
J1002
(U)SIM2 card connector
MEMS-Type
ECM-Type
