Note:Themaximumlengthfortheradarpower
anddatadigitalcable(includinganyextensions)
is25m(82ft).
4.9Sonarconnection
Asonarconnectionisrequiredtoenableuseofthe
Fishnderapplication.
TheMFDcanbeusedwiththefollowingRaymarine
sonarmodules:
•CP450C
•CP300
•CP200
•CP100
Thereare2typesofconnectionrequiredfor
Fishnderapplications:
•Sonarmoduleconnection—convertsthesonar
signalsprovidedbythesonartransducerinto
datasuitableforamarineelectronicssystem.
Thesonarvariantmultifunctiondisplaysfeature
abuilt-insonar,enablingyoutoconnectthe
displaydirectlytoacompatiblesonartransducer.
Non-sonarvariantsrequireaconnectiontoan
externalRaymarinesonarmodule.Internal
andexternalsonarsrequireaconnectiontoa
compatiblesonartransducer.
•Sonartransducerconnection—providessonar
signalstothesonarmodule.
Sonarmoduleconnection
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
D12255-1
1
2
3
4
1.Rearconnectorpanelofmultifunctiondisplay
(Non-sonarvariant).
2.Raymarinenetworkswitch.
3.Raymarinesonarmodule.
4.RayNetcable.
Ifasparenetworkconnectionisavailableonyour
multifunctiondisplaythenasonarmodulemaybe
connecteddirectlytothedisplay,withoutusinga
Raymarinenetworkswitch.
Note:YoucanalsoconnectasonarvariantMFD
toaRaymarine
®
sonarmodule.Thisisusefulin
circumstanceswhereyouneedahigherpowered
sonarmoduleforexample.
Multipleactivesonarmodules
Multipleactivesonarmodulescanbepresentonthe
samenetwork,youmustselectwhichsonarmodule/
channelyouwanttouseintheFishnderapplication.
