Important:Raymarine

doesnotguarantee

compatibilitywiththird-partyIPcameras.

4.12Weatherreceiverconnection

YoucanconnectaSiriusXMweatherreceiverto

yourmultifunctiondisplay.

RayNet

AUDIO

ANTENNA

NETWORK

POWER

D12902-2

1.Raymarineweatherreceiver.

2.Multifunctiondisplay.

Theweatherreceivercanalsobeconnectedtoa

Raymarinenetworkswitch.

ForinformationonconnectinganSR50using

SeaTalk

pleasereferto82257–SR50operation

whichcanbedownloadedfromtheRaymarine

website:www.raymarine.com.

Cablesandconnections65
