4.13Fusionlinkconnection
YoucanconnectaFusion700seriesmarine
entertainmentsystemtoyourmultifunctiondisplay.
Directconnection
1
2
3 4
D12741-1
1.Multifunctiondisplay.
2.Fusionsystem.
3.RayNettoSeaTalk
hs
cable.
4.Fusionethernetconnector.
Directconnectionwithnetworkedmultifunction
displays
3 2
D12742-1
4
1
5
1.Fusionsystem.
2.Fusionethernetconnector.
3.RayNettoSeaTalk
hs
cable.
4.Directlyconnectedmultifunctiondisplay.
5.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcanbe
controlledbyadirectlyconnectedmultifunction
displayorbyanetworkedmultifunctiondisplay.
Networkconnection
D12740-1
6
5
1
2
6
3 4
1.Networkswitch.
2.Fusionsystem.
3.RayNettoSeaTalk
hs
cable.
4.Fusionethernetconnector.
5.SecondFusionsystem(themultifunction
displaycanbeconnectedtomultipleFusion
entertainmentsystems).
6.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcan
becontrolledbyanycompatiblenetworked
multifunctiondisplaywhenconnectedusinga
networkswitch.
