Raymarine Axiom 2 Pro 16 RVM User Manual

23.
1Powerspecification
Specification
Nominalsupplyvoltage:
12V/24Vdc
Operatingvoltagerange:
8Vdcto32Vdc
Current(Maximum):
5A
Off-current(Maximum@12
Vdc):
11mA(0
.13Watts)
Off-current(Maximum@
24Vdc):
18mA(0.43Watts)
Fuserequirements:
•Inlinefuse=5Amp ,or
•Thermalbreaker=5Amp
PowerconsumptionMax@
12Vdc:
•RVM:50.8Watts
•S:38.4Watts
P owerconsumptionMax@
24Vdc:
•RVM:47.1Watts
•S:37.7Watts
Note:
P owerconsumptionfiguresforRVMvariantdisplaysweretakenusinga
RealVision™Maxtransducerconnected.PowerconsumptionfiguresforS
variantdisplaysweretakenusingaCPT-Stransducerconnected.
23.2Environmentalspecification
Specification
Operatingtemperature
range:
-25°C(-13°F)to+55°C(131°F)
S toragetemperaturerange:
-30°C(–22°F)to+70°C(158°F)
Humidity:
upto93%@40°C(104°F)
W ateringressprotection:
IPx6andIPx7
Installationlocation:
•Abovedecks
•Belowdecks
23.3L
CDspecification
Specification
Size(diagonal):
15.6”
T
ype:
IPS(In-PlaneSwitching)
Colordepth:24-bit
R
esolution:
1920x1080(FullHD)
Ratio:
16:9
Illumination:
1200nits/1200cd/m
2
Viewingangle:
Top88°/Bottom88°/Left88°/Right88°
Numberofsimultaneous
touches:
1to16
23.4Physicalspecification
Specification
Gross(boxed)product
weight:
•Svariant:9.02kg(19.89lbs)
•RVMvariant:9.18kg(20.24lbs)
Net(unboxed)product
weight:
•Svariant:5.98kg(13.18lbs)
•RVMvariant:6.02kg(13.27lbs)
Dimensions(surface/flush
mounted):
Height:258mm(10.16in),Width:452.02
mm(17.8in),Depth(includingcables):240.4
mm(9.46in)
Dimensions(trunnion
mounted):
Height:281.20mm(11.10in),Width:482.50
mm(19.00in),Depth(includingcables):
241.40mm(9.50in)
Internalstorage:
64GBsolidstate.
Externalstorage:
DualslotMicroSDXCcardreader
Axiom2Pro16technicalspecification
103
