21.
1Powerspecification
Specification
Nominalsupplyvoltage:
12V/24Vdc
Operatingvoltagerange:
8Vdcto32Vdc
Current(Maximum):
5A
Off-current(Maximum@12
Vdc):
11mA(0
.13Watts)
Off-current(Maximum@
24Vdc):
18mA(0.43Watts)
Fuserequirements:
•Inlinefuse=5Amp ,or
•Thermalbreaker=5Amp
PowerconsumptionMax@
12Vdc:
•RVM:44.4Watts
•S:31.2Watts
P owerconsumptionMax@
24Vdc:
•RVM:40.9Watts
•S:29.6Watts
Note:
P owerconsumptionfiguresforRVMvariantdisplaysweretakenusinga
RealVision™Maxtransducerconnected.PowerconsumptionfiguresforS
variantdisplaysweretakenusingaCPT-Stransducerconnected.
21.2Environmentalspecification
Specification
Operatingtemperature
range:
-25°C(-13°F)to+55°C(131°F)
S toragetemperaturerange:
-30°C(–22°F)to+70°C(158°F)
Humidity:
upto93%@40°C(104°F)
W ateringressprotection:
IPx6andIPx7
Installationlocation:
•Abovedecks
•Belowdecks
21.3L
CDspecification
Specification
Size(diagonal):
9
.0”
T
ype:
IPS(In-PlaneSwitching)
Colordepth:24-bit
R
esolution:
1280x720(HD)
Ratio:
16:9
Illumination:
1300nits/1300cd/m
2
Viewingangle:
Top88°/Bottom88°/Left88°/Right88°
Numberofsimultaneous
touches:
1to16
21.4Physicalspecification
Specification
Gross(boxed)product
weight:
•Svariant:5.03kg(11.09lbs)
•RVMvariant:5.16kg(11.38lbs)
Net(unboxed)product
weight:
•Svariant:2.82kg(6.22lbs)
•RVMvariant:2.98kg(6.57lbs)
Dimensions(surface/flush
mounted):
Height:173.79mm(6.84in),Width:299.32
mm(11.78in),Depth(includingcables):
234.9mm(9.25in)
Dimensions(trunnion
mounted):
Height:186.2mm(7.33in),Width:329.5mm
(12.97in),Depth(includingcables):234.9
mm(9.25in)
Internalstorage:
64GBsolidstate.
Externalstorage:
DualslotMicroSDXCcardreader
Axiom2Pro9technicalspecification
93
