Raymarine Axiom 2 Pro 16 RVM User Manual

24.
1Compatibletransducers
Foralistoftransducersthatarecompatiblewithyoursonarmodule,referto
thefollowingsection:p.20—Compatibletransducers.
Inaddition,thefollowingspeed/tempsensingtransducersarealso
compatiblewithyoursonarmodule:
Itemdescriptionandpartnumbers
•S
T800–P120Plasticlow-profilespeed/tempsensor—E66071
•ST800–B120Bronzelow-profilespeed/tempsensor—E66072
24.2Spares
ThefollowingsparesareavailableforAxiom®2Prodisplays.
Description
P artnumber
Axiom®2Pro9suncoverA 80741
Axiom®2Pro12suncoverA 80742
Axiom®2Pro16suncoverA80743
Axiom®2Pro9trunnionkitR70384
Axiom®2Pro12trunnionkitR70389
Axiom®2S traightpower/video/audiocable
-1.5m(4.92ft)
A80744
Axiom®2ProcardreaderdoorreplacementR70891
Axiom®2Pro12and16k eypadinfill
replacements(2xinfillssupplied)
R70892
Axiom®2ProLowerkeypadreplacement
(1xpilotkeypad,1xuserprogrammable
keypad)
R70888
Axiom®2Pro9 ,12,16LeftHandBungs
replacements(3xbungssupplied)
R70893
24.3Accessories
ThefollowingaccessoriesareavailableforAxiom®2Prodisplays.
Description
P
artnumber
Axiom®2Pro16trunnionkitA
80722
Axiom®2rightangledpower/video/audio
cable-1.5m(4.92ft)
A
80745
BlankNameplaque(QTY:40)
A80724
BulkheadMountMicroUSBSocketA80630
Actisense®NGW-1NMEA2000(DeviceNet)
toNMEA0183converter
A80721
GA200passiveGNSS(GPS)antenna
A80589
GA150passiveGNSS(GPS)antenna
A80288
MicroHDMI(TypeD)cable5m(16.4ft)cable
A80723
RCR-1cardreaderA80585
RCR-SDUSBcardreaderA80440
RMK-10—displayremotecontrol
A80438/T70293
Transducercables
RealVision™Max3D/RealVision™3Dtransducerextensioncable(s):
•3m(9.8ft)RealVision™transducerextensioncable—A80475
•5m(16.4ft)RealVision™transducerextensioncable—A80476
•8m(26.2ft)RealVision™transducerextensioncable—A80477
•0.3m(1ft)RealVision™90-degreeadaptercable—A80515
•PairedRealVision™transducerY-cable—A80478
DownVision™/SideVision™/CPT-SCHIRPconicalbeamtransducer
extensioncable(s):
•25-pinto9-pinDownVision™transduceradaptercable—A80490
CHIRP/Traditionaltransducerextensioncable(s):
•11-pinto8-pinCP370-styletransduceradaptercable—A80496
•5m(16.4ft)traditionaltransducerextensioncable—E66010
108
