22.5Connectionsspecification
Specification
Accessoryconnection:
USBMicroB(fore
xternalcardreader
connection).
Analogvideoconnections:
CompositeBNCconnectorsvia
P
ower/Video/Audiocable.
Audioconnections:
LeftandRightRCAconnectorsvia
Power/Video/Audiocable.
Ethernetconnections:
R ayNet(10/100/1,000Mbits/s)x2.
GPSantennaconnection:
TNCtypeconnector.
HDMIconnections:
MicroHDMI(T ypeD)(v1.4b)output
connector.
NMEA0183connection:
NMEA0183TONMEA2000convertor
required(partnumber:A80721).
NMEA2000connection:
DeviceNetconnector(L oadEquivalency
Number=1).
Bluetoothconnection:
Bluetooth:v4.0combinedwithWi-Fi
module.
Wi-Ficonnection:
Multiband-2.4GHz,and5Ghz802. 11b/g/n
•DualMIMO(MultipleIn,MultipleOut)@
2.4GHz
–1xAntennaisusedforWi-Fionly
–1xAntennaisusedforbothWi-Fiand
Bluetooth
2.4GHzonly(cansimultaneouslyoperateas
anaccesspointandasahost)
•SISO(SingleIn,SingleOut)@5GHz
–1xAntennaisusedforWi-Fionly
–1xAntennaisusedforBluetoothonly
Specification
T
ransducerconnections
(RVMvariants):
•25-pinRV/RVMconnector.
•11-pin1kWconnector.
T
ransducerconnections(S
variants):
25-pinRV/RVMconnector(requires
adaptorcableforCPT-Sonlytransducers.
22.6InternalGNSS(GPS)receiverspecification
Specification
AlmanacUpdate:Automatic
Antenna:Internalantenna,optionalexternalantenna
connection.
Channels:Trackupto28satellitessimultaneously.
Coldstart(TimeToFirst
Fix):
<2minutes.
GeodeticDatum:
WGS-84(alternativescanbeselectedon
thedisplay)
GNSScompatibility:
•GPS
•GLONASS
•Beidou
•Galileo
Operatingfrequency:
1574MHzto1605MHz.
PositionAccuracy:
•WithoutSBAS:<=15meters95%ofthe
time.
•WithSBAS:<=5meters95%ofthetime.
ReceiverICSensitivity:
•165dBm(Tracking)
•160dBm(Re-acquisition)
•148dBm(Coldstart)
RefreshRate:
10Hz(10timespersecond)
Axiom2Pro12technicalspecification
