1Axiom®2ProRVMvariant—compatible
transducers
Thefollowingtransducertypescanbeconnectedtothetransducer
connectionsonAxiom®2ProRVMvariantMFDs:
RV/RVMconnection:
•p.21—RealVision™Max3Dtransducers
•p.21—RealVision™3Dtransducers
•p.22—SideVision™transducers
•p.23—DownVision™transducers
•p.23—CPT-Sconicalbeamtransducers
1kWconnection:
•p.23—CHIRPtransducers
•p.25—Traditionaltransducers
RealVision™Max3Dtransducers
•RealVision™Max3Dtransducersconnectdirectlytothe25–pinRV/RVM
transducerconnector.
•RealVision™Max3Dsplit-pairtransducersaresuppliedwithaY-cable(part
number:A80478)andextensioncable(partnumber:A80477)toconnect
bothtransducerstothe25–pinRV/RVMtransducerconnector.
T
ransommounttransducers
P
artnumber
Transducerdescription
A
80703RVM-100RealVision™Max3Dplastictransducer
Thru-hullmounttransducers
P
artnumber
Transducerdescription
A
80704RVM-400RealVision™Max3Dstainlesssteel0°transducer
T70543:
A80705
A80706
RVM-412P/RVM-412SRealVision™Max3Dstainlesssteel
12°split-pairtransducers
T70544:
A80707
A80708
RVM-420P/RVM-420SRealVision™Max3Dstainlesssteel
20°split-pairtransducers
RealVision™3Dtransducers
•RealVision™Max3Dtransducersconnectdirectlytothe25–pinRV/RVM
transducerconnector.
•RealVision™Max3Dsplit-pairtransducersaresuppliedwithaY-cable(part
number:A80478)andextensioncable(partnumber:A80477)toconnect
bothtransducerstothe25–pinRV/RVMtransducerconnector.
Compatibletransducers
21
