1Partssupplied-Axiom2Pro9/12
Thefollowingpartsaresuppliedinthebox.
Unpackyourproductcarefullytopreventdamageorlossofparts.Checkthe
boxcontentsagainstthelistbelow.Retainthepackaginganddocumentation
forfuturereference.
Item
Description
1
Axiom®2Prodisplay
2Userconfigurablelowerk eypad
3Suncover
4Mountinggask et
5
*
Trunnionmountingbracket
6
T runnionknobs
7
M3x5screw,M3springwasherandM3crimpterminal(for
optionalgroundingconnection)
8
Sea Talkng™toDeviceNetadaptorcable,1m(3.3ft)
9
RayNetnetworkcable,2m(6.6ft)
Item
Description
10
Mountingfixingsx4(includingM4x40bolts,M4plainwashers,
M4nuts)
11Documentation
12
P
ower/video/audiocable,1.5m(4.92ft)
Note:
*Fixingstosecurethetrunnionbrack
ettoamountingsurfacearenot
provided.5xselftappingscrewsarerequired.Thescrewsshouldbe
suitableforthemountingsurfacematerialandthe5.75mm(0.23in)
diametermountingholesinthetrunnionbracket.
