AIR VENTS (continued)
Air flow
Move thumbwheel 1 (beyond the
pointofresistance).
Up: maximum flow.
Down: closed.
Move thumbwheel 4 (beyond the
pointofresistance).
Up: maximum flow.
Down: closed.
Direction
Right/left: move the tabs 2 or 3.
Up/down:lowerorraisethetabs2
or 3.
