REAR LIGHTS: replacing bulbs
Direction indicators/brake and
side lights
After opening the boot, remove
bolts 1.
Release the rear light assembly from
outside the vehicle by pulling it
towards the rear.
Unclip the bulb holder 2 to access
the bulbs.
Note: when refitting make sure the
cable is replaced.
3 Brake and side light
P21/5 W bulb.
4 Direction indicator light
PY21 W orange bulb.
5 Rear fog light
P21 W bulb.
(Both lens units are fitted with a
bulb, but only the bulb on the
driver's side works)
6 Reversing light
P21 W bulb.
