3.49
LUGGAGE NET
If fitted, this can be used when
transporting animals or luggage to
isolate them from the passenger
section.
It can be positioned:
- behind the front seats using
anchorage points 1,
- behind the rear seats using
anchorage points 2.
Fitting the luggage net behind
the front seats
Inside the vehicle on each side:
- lift the cover 1 to gain access to the
anchorage points for the top part
of the luggage net,
- insert the top rod of net 3 into the
anchorage points,
-attachhook4 on the net strap to
the lower ring located under the
rear of the front seat (if necessary,
move the seat forward to access it),
- adjust net strap 5 so that it is taut.
