REAR PARCEL SHELF: normal chassis
Rear parcel shelf
To remove, unhook the two straps 1
from the tailgate.
Fold down section A on parcel
shelf B, then pull towards you.
Never place anything,
especially heavy or hard
objects, on the rear parcel
shelfwhenitisinthe
raised position.
Thesemayposearisktothe
vehicle occupants if the driver
has to brake suddenly or if the
vehicle is involved in an
accident.
Carry out the reverse operation to
refit the shelf.
Rear parcel shelf raised
positions
Position the rear parcel shelf on the
supports 2 located at mid-height in
the boot.
Maximum weight on the rear
parcel shelf at mid-height or in
lower position = 25 kg.
