ROOF BARS
Each roof trim is fitted with hatches
enclosing the roof bar mounting
points.
Each of the hatches is shut by a
pivoting flap (1).
Access to the mounting points
Pivot each flap 1 upwards.
For vehicles not fitted with flaps 1,
see your RENAULT Dealer.
Special features of long chassis
vehicles
When in use, the roof bars must be
positioned only at points A and B.
Points C and D are only storage
positions for the roof bars.
Maximum permissible load on the
roof rack: refer to the section
entitled “Weights” in Section 6.
Refer to the manufacturer's
instructions for information on
how to fit and use the roof rack bar.
Please keep these instructions with
therestofthevehicle
documentation.
