Rigol DS7000 Series User Programming Manual

RIGOL Chapter 2 Command System
2-90 MSO7000/DS7000 Programming Guide
:MASK Commands
The :MASK commands are used to set or query the relevant parameters of the pass/fail test.
Command List:
 :MASK:ENABle
 :MASK:SOURce
 :MASK:OPERate
 :MASK:MDISplay
 :MASK:X
 :MASK:Y
 :MASK:CREate
 :MASK:RESet
:MASK:ENABle
Syntax
:MASK:ENABle <bool>
:MASK:ENABle?
Description
Enables or disables the pass/fail test function; or queries the on/off status of the pass/fail
test function.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Remarks
The pass/fail test function is invalid in the following conditions: when the horizontal time
base mode is XY or ROLL; when in the slow sweep mode (i.g. the horizontal time base
mode is YT, and the horizontal time base is 200 ms/div or slower); when in waveform
recoding.
Return
Format
The query returns 1 or 0.
Example
:MASK:ENABle ON /*Enables the pass/fail test function.*/
:MASK:ENABle? /*The query returns 1.*/
:MASK:SOURce
Syntax
:MASK:SOURce <source>
:MASK:SOURce?
Description
Sets or queries the measurement source of the pass/fail test.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Remarks
This command can only set the enabled channel, and you can send
the :CHANnel<n>:DISPlay command to enable the desired channel.
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MASK:SOURce CHANnel2 /*Sets the measurement source of the pass/fail test to CH2.*/
:MASK:SOURce? /*The query returns CHAN2.*/
