Rigol DS7000 Series User Programming Manual

Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-149
:SYSTem:AOUTput
Syntax
:SYSTem:AOUTput <aux output>
:SYSTem:AOUTput?
Description
Sets or queries the type of the signal output from the [TRIG OUT] connector on the
rear panel.
Parameter
Name
Type
Range
Default
<aux output>
Discrete
{TOUT|PFAil}
TOUT
Remarks
 TOUT: after you select this type, the oscilloscope initiates a trigger and then a
signal which reflects the current capture rate of the oscilloscope can be output
from the [TRIG OUT] connector.
 PFAil: after you select this type, a pulse signal will be output from the [TRIG
OUT] connector once the oscilloscope detects a successful or failed event.
Return
Format
The query returns TOUT or PFA.
Example
:SYSTem:AOUTput PFAil /*Sets the signal type to PFAil.*/
:SYSTem:AOUTput? /*The query returns PFA.*/
:SYSTem:AUTOscale
Syntax
:SYSTem:AUTOscale <bool>
:SYSTem:AUTOscale?
Description
Enables or disables the function of the front-panel AUTO key; or queries the on/off
status of the AUTO key on the front panel.
Parameter
Name
Type
Range
Default
<bool>
Bool
{{1|ON}|{0|OFF}}
1|ON
Remarks
 You can send this command or press Utility  More  Auto Config  Lock
disable the function of the AUTO key, but you can only send this command to
enable this key.
 After the function of the AUTO key is disabled, you cannot perform the Auto
Scale operation. The :AUToscale command is invalid.
Return
Format
The query returns 1 or 0.
Example
:SYSTem:AUTOscale ON /*Enables the function of the front-panel AUTO key.*/
:SYSTem:AUTOscale? /*The query returns 1.*/
