RIGOL Chapter 2 Command System
2-182 MSO7000/DS7000 Programming Guide
:TRIGger:RUNT
Command List:
 :TRIGger:RUNT:SOURce
 :TRIGger:RUNT:POLarity
 :TRIGger:RUNT:WHEN
 :TRIGger:RUNT:WUPPer
 :TRIGger:RUNT:WLOWer
 :TRIGger:RUNT:ALEVel
 :TRIGger:RUNT:BLEVel
:TRIGger:RUNT:SOURce
Syntax
:TRIGger:RUNT:SOURce <source>
:TRIGger:RUNT:SOURce?
Description
Sets or queries the trigger source of Runt trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:RUNT:SOURce CHANnel2 /*Sets the trigger source to CH2.*/
:TRIGger:RUNT:SOURce? /*The query returns CHAN2.*/
:TRIGger:RUNT:POLarity
Syntax
:TRIGger:RUNT:POLarity <polarity>
:TRIGger:RUNT:POLarity?
Description
Sets or queries the polarity of Runt trigger.
Parameter
Name
Type
Range
Default
<polarity>
Discrete
{POSitive|NEGative}
POSitive
Remarks
 POSitive: indicates the positive polarity. The oscilloscope triggers on the positive
polarity of Runt trigger.
 NEGative: indicates the negative polarity. The oscilloscope triggers on the
negative polarity of Runt trigger.
Return
Format
The query returns POS or NEG.
Example
:TRIGger:RUNT:POLarity NEGative /*Sets the polarity of Runt trigger to NEGative.*/
:TRIGger:RUNT:POLarity? /*The query returns NEG.*/
