Rigol DS7000 Series User Programming Manual

RIGOL Chapter 2 Command System
2-16 MSO7000/DS7000 Programming Guide
:BUS<n>:RS232 (Option)
The :BUS<n>:RS232 commands are used to set relevant parameters for RS232 decoding.
Command List:
 :BUS<n>:RS232:TX
 :BUS<n>:RS232:RX
 :BUS<n>:RS232:POLarity
 :BUS<n>:RS232:ENDian
 :BUS<n>:RS232:BAUD
 :BUS<n>:RS232:DBITs
 :BUS<n>:RS232:SBITs
 :BUS<n>:RS232:PARity
 :BUS<n>:RS232:PACKet
 :BUS<n>:RS232:PEND
:BUS<n>:RS232:TX
Syntax
:BUS<n>:RS232:TX <source>
:BUS<n>:RS232:TX?
Description
Sets or queries the TX channel source of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
OFF
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:BUS1:RS232:TX D0 /*Sets the TX channel source of RS232 decoding to D0.*/
:BUS1:RS232:TX? /*The query returns D0.*/
:BUS<n>:RS232:RX
Syntax
:BUS<n>:RS232:RX <source>
:BUS<n>:RS232:RX?
Description
Sets or queries the RX channel source of RS232 decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
OFF
Return
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
