4 Publication: AMEN00064 2019‑03‑07
Revolution
®
HVLS Fan • Rogue
®
HVLS Fan Installation/Service/Owner's Manual Rite‑Hite
®
INSTALLATION
Components
Before installation, verify all components were received.
Notify your Rite‑Hite representative if parts are missing
or damaged.
• 1 box: Motor, hub assembly, remote mounted control
switch and disconnect switches. ≈ 160lb [73kg]
• 1 box: Mounting hardware and cables. ≈ 50lb [23kg]
• 1 box: Control box. ≈ 35lb [16kg]
• Revolution Fan: 4 blades
• Rogue Fan: 2 blades
Required Tools
2
7/16in wrenches
(1 can be socket/driver)
2
1/2in wrenches
2
9/16in wrenches
2
3/4in wrenches
1 Vice grip
2
Flat screwdrivers (large and small)
1
Small standard screwdriver
1
Medium Phillips screwdriver
1
Torque wrench, minimum 200‑ft‑lb (270 Nm), 1/2in drive
1
1/2in to 3/4in socket adapter
1
1/2in socket extender
1
Metric 7mm deep well socket – or Driver
1
1/4in cable cutter
4
Crimp on ring terminals, M4 (#8) stud, for motor wiring
1
Torpedo level
1
Drill and 1/2in drill bit. If mounting to support angles that
span building joists
Specifications
Diameter (Ø) 8ft, 12ft, 16ft, 20ft and 24ft
[2440mm, 3660mm, 4880mm,
6100mm and 7320mm]
Blades Aluminum
Blade Finish Mill-nish standard,
custom colors optional
# of Blades 2 (Rogue) or 4 (Revolution)
Watts 75 (@ 10Hz) to 1750 (@ 60Hz) Typical
Frequency 50/60 Hz
Coverage Up to 22,000sq ft [2046m
2
] 85ft [26m] from the fan’s
center in all directions
Decibels 40 to 63 dBA depending on fan speed
(measured 20ft [6100mm] below and 20ft [6100mm]
from the fan’s center)
Air Speed Up to 7mph [3m/s] at full speed
Controls Variable speed
Mounting
Heights
10ft - 80ft [3m - 24m] from nished oor to bottom of
blade
Fan Ø RPM Weight
8ft [2440mm] 30‑150 268lb [122kg]
12ft [3660mm] 18‑96 276lb [125kg]
16ft [4880mm] 15‑74 284lb [129kg]
20ft [6100mm] 12‑59 292lb [132kg]
24ft [7320mm] 10‑52 300lb [136kg]
Revolution and Rogue
2 HP (1.5 kW)
Supply Voltage
200‑240V
1
ɸ
200‑240V
3
ɸ
400‑480V
3
ɸ
Fan Input Current (Amps) 13 7 3.5
Control Box Fuse Rating
(Amps)
20 15 10
Minimum Service Amps 20 15 10
Maximum Number of Fans per Branch Circuit
Branch
Circuit
Amps
15 NA 1 3
20 1 2 4
25 1 2 5
30 1 3 6
35 2 4 8
40 2 4 9
