Program a Function Block Diagram
30 Rockwell Automation Publication 1756-PM009G-EN-P - February 2018
Wire connectors that share the same connector name can be changed in a
routine.
Tip:
If there are wire connectors with the new name, the
renamed wire connectors merge with the existing
connectors.
1. Right-click the operand area of the desired ICON or OCON, and click
Rename Connector Group.
2. In the box, type or select the new name and press Enter.
All instances in the group are changed to the new name.
As you program your routine, periodically verify your work.
1. On the Standard toolbar, click the Verify icon.
If there are errors, they are listed in the Output window on the Errors
tab at the bottom of the Logix Designer application.
2. Press F4 to go to the first error or warning.
3. Correct the error according to the description in the Errors tab.
4. Repeat steps 1...3 until all of the errors are corrected.
5. To close the Output window, press Alt + 1.
