2-1 Installing
Chapter 2:
Prepar
ing the GX
21
Remo
ving the P
acking Materials
T
ape and packing materials are attac
hed to the machine to protect it from vibration during tr
ansportation. When
installation is complete, remov
e these.
➢
Remove all packing materials.
Any that remain ma
y cause faulty operation or br
eakdown when the pow
er is
switched on.
