Chapter 4: Performing Cutting
53
4-2 Using a Variety of Materials
Using Roll Material or Lengthy Flat Material
With this machine, you can use not only such standard-size material as the test-use material, but also lengthy flat
material, as well as roll material (sold separately). To use flat material or roll material whose length is more than 1.6
meters, follow the steps below.
Procedure
1.
(For roll material) Install the roller base, then secure the roll material in place.
If you're using flat material that is longer than 1.6 meters, refer to "Step 1: Load Material" on page 36 to secure the
material in place, then go on to the next page.
➊
Install the roller base.
➋
Make sure that the loading lever is lowered.
➌
Place the roll material on the roller base.
Pull out material, then pass its leading edge through the machine and out to the front of the
machine.
Pull out
a length of material that is slightly longer than the amount needed for cutting, leaving some
slack.
➍
Go to "Step 1: Load Material" on page 36 and carry out the operations from "1. Load the material.
--
➋
" and after to secure the material in place.
Grasp the end
of the machine
and lift up.
Be sure to pull out the material.
Loading material without pulling it out
makes correct material feed impossible.
Continued on the next page
Fit into the groove.
Loading lever
OK Not OK
To Next Page
