Chapter 7: Appendix
66
7-3 Specifications
*1
According to material and cutting conditions as specified by Roland DG Corp. (using the PNS-24 stand, sold separately).
*2
➢ Excluding material expansion and contraction.
➢ Provided that media length is under 3000 mm
*3
According to Roland DG Corp. measurement criteria.
➢ Using the included software from Roland DG Corp.
➢ Using a laser or ink-jet printer having a resolution of 720 dpi or better.
➢ Excluding glossy or laminated material.
➢ Excluding effects of printing distortion due to printer precision and effects of material expansion, contraction, or warping.
➢ Depending on the ink (black) employed by the printer used, correct sensing may not be possible.
Driving method
Cutting method
Loadable material width
Maximum cutting area
Acceptable tool
Maximum cutting speed
Cutting speed
Blade force
Mechanical resolution
Software resolution
Distance accuracy
(*1)
Repetition accuracy
(*1) (*2)
Alignment accuracy for printing and cut-
ting when loading printed material
(*1) (*3)
Interface
Replot memory
Instruction system
Power supply
Power consumption
Acoustic noise level During operation
During standby
Dimensions
Weight
Packed dimensions
Packed weight
Environment
Included items
GX-24
Digital controll servo motor
Media-moving method
50 to 700 mm (2 to 27-1/2 in.)
Width: 584 mm (22-15/16 in.)
Length: 24998 mm (984-1/8 in.)
Special blade for CAMM-1 series
500 mm/s (All direction)
10 to 500 mm/s (All direction)
30 to 250 gf
0.0125 mm/step (0.000492 in./step)
0.025 mm/step (0.000984 in./step)
Error of less than ±0.2% of distance traveled, or ±0.1 mm, whichever is greater
±0.1 mm or less
±1 mm or less for movement distance of 210 mm or less in material-feed direc-
tion and movement distance of 170 mm or less in width direction (Excluding
effects of printer and/or material)
USB interface (compliant with Universal Serial Bus Specification Revision 1.1)
Serial (RS-232C)
800 KByte
CAMM-GL III
Dedicated AC adapter
Input: AC 100 to 240 V ± 10 % 50/60 Hz 1.7 A
Output: DC 24 V, 2.8 A
Approx. 30 W (including AC adapter)
70 dB (A) or less (according to ISO 7779)
40 dB (A) or less (according to ISO 7779)
855 (W) X 315 (D) X 240 (H) mm (33-11/16 (W) x 12-3/8 (D) x 9-7/16 (H) in.)
16 kg (35 lb.)
1050 (W) X 450 (D) X 390 (H) mm (41-3/8 (W) x 17-3/4 (D) x 15-3/8 (H) in.)
22 kg (49 lb.)
Temperature: 5 to 40˚C (41 to 104˚F), humidity: 35 to 80% (no condensation)
AC adapter, power cord, blade, blade holder, separating knife, roller base, twee-
zers, test-use material, application tape, USB cable, CD-ROM, user's manual
