18
Creating a Kit
Editing the Sound of the Overall Kit
* For details on the parameters, refer to “Data List” (PDF).
Button Parameter Value Explanation
[KITCOMMON]
KitVolume 0–127 Species the volume of the entire kit.
PedalHHVolume 0–127 Species the volume of the pedal hi-hat.
KitTempo 20–260
Species the tempo setting of each kit.
If the MFX Tempo Sync is ON, eect settings such as Rate and Delay Time reect
the tempo specied here.
* For details on MFX, refer to “Data List” (PDF).
KIT COMP –
Adjusts the volume dynamics of the entire kit. This makes settings for the
compressor that is applied at the nal stage of the output.
For details, refer to “KIT COMP settings” (p. 18).
KIT EQ –
Adjusts the tonal character of the entire kit. You can adjust the amount of boost/
cut for three bands (LOW, MID, HIGH). You can also use this to adjust the tonal
character when using KIT COMP.
For details, refer to “KIT EQ settings” (p. 19).
KIT NAME –
Edits the name of the kit.
Use the [K][J] buttons to select the character that you want to edit, and use the
[–][+] buttons to edit it.
KIT MIDI –
Here you can specify the MIDI messages that a pad sends or receives.
For details, refer to “KIT MIDI settings” (p. 19).
KIT RESET KIT001–KIT200 Returns the kit to its factory-set state.
KIT COMP settings
Parameter Value Explanation
ON/OFF ON, OFF Turns KIT COMP on/o
TYPE SOFT, HARD, LIMITER
Type of compressor
* When you change this parameter, all parameters in KIT COMP are changed to the optimal
settings. Based on these settings, you can edit each parameter as desired.
Gain -24.0–+24.0dB Output volume of the compressor
Thre -48–0dB Volume level at which compression starts
Ratio
1:1, 2:1, 3:1, 4:1, 8:1,
16:1, 32:1, 100:1
Compression ratio
Knee
HARD, SOFT1,
SOFT2, SOFT3
Attack of the sound at the moment that compression is applied
Attack 0.1–100ms Time until compression starts
Release 10–1000ms Time over which compression returns to the original state
To Next Page
