Roland XV-5080. Quick Start

46
Let’s Play Sounds From a Sampler Library
Loading Sampler Libraries (Patches)
Here’s how you can load Patches from a library (optional L-CDX Series)
designed for use with the XV-5080 (S-760).
fig.00-047.e_80
1
Turn on the power to the CD-ROM drive, then to the XV-5080.
2
Place the CD-ROM (sampler library) that you want to load in
the CD-ROM drive.
3
Press [DISK] button.
The Disk Menu page appears.
fig.00-048.e_80
4
Press [F1 (Load)] button.
The Load page will appear.
fig.00-049.e_80
5
Press [F1 (Drive)] button.
The Drive window will appear.
For more detailed
information and
instructions for loading
data, refer to “Chapter 7
Loading Each Type of
Data” in the Owner’s
Manual.

Roland XV-5080. Specifications

General

Polyphony	128 voices
Multitimbral Parts	32 parts
Display	240 x 64 dot backlit LCD
MIDI	In, Out, Thru
Sampling Frequency	44.1 kHz
Wave Memory	64 MB
Effects	Reverb, Chorus
Dimensions	482 (W) x 88 (H) mm
Outputs	8 x individual (1/4"), stereo mix (1/4"), headphones
