Rotax 914 series Maintenance Manual

74-00-00
page 24
May 01/2007
Effectivity 912 Series
Edition 1 / Rev. 0
d02624
BRP-Rotax
Maintenance Manual
3.13) Wiring diagrams
3.13.1) Engine internal (on the 912 Series)
Wiring diagram of the ignition unit ("individual plug"), 912 Series
See Figs. 74-18, 74-19 and 74-20.
Legend to wiring diagram (Fig. 74-18)
1 ignition magneto generator
2 trigger coil for ignition circuit ”A”
3 trigger coil for ignition circuit ”B”
4 trigger coil for rev counter
5 plug receptacle 2-pin
6 electronic rev counter
7 grounding switch for ignition circuit ”A” and ”B”
8 plug receptacle 1-pin
9 plug receptacle 4-pin
10 electronic module for ignition circuit ”A”
11 electronic module for ignition circuit ”B”
12 double ignition coil
13 engine
14 cylinder 1-4
15 spark plugs
16 charging coils
V consumer connection
o color code
