Troubleshooting
4-66 Samsung Electronics
4-4-22 Communication Error between Indoor and Outdoor Units during Tracking
×(Operation) ስ (Reservation) ስ (Blast) ×(Filter) ×(Defrost)
 Refer to the judgment method below .
 Communication error between indoor and outdoor units.
Indoorunit display
Judgment Method
Cause of problem
Outdoor unit display
1.
Cause of problem
Yes
Yes
Indoor Unit Installation Quantity Setup Switch of
Outdoor Unit Compare and check the set value and the
actual number of indoor units installed.
Press the reset key (K3) of the outdoor PCB, and check
the display module to check for the qu
antity of indoor
units that respond to the tracking.
Remove the communication cable which connects
the outdoor unit to the indoor unit, and measure the 2
cables of the outdoor unit with a scope.
Is there no sign of
the indoor response on the
display
during tracking?
Check the communication cable
which connects the outdoor unit to the indoor unit.
If there is no peculiarity, then connect the indoor units one by one
to find the indoor unit that is interfering with the communication for
inspection and change the indoor unit PCB.
Is the voltage between
the 2 cables a square wave with
DC±0.7V or more?
Are the number of
actual installed indoor units and the set value for the
installation quantity setup
switch
the same?
Correctly set the indoor unit installation quantity
setup switch of the outdoor unit, and press the reset
key (K3) of the outdoor PCB to re-execute tracking.
After 2 minutes, find the indoor unit which displays
the communication
error for the indoor units, and
check for overlaps in the PCB address setup.
(If the indoor unit addresses are overlapped,
then a communication error will occur).
- In this case, a communication error will occur
in every indoor unit (two or
more units) with
the address incorrectly set.
Change the indoor unit PCB after checking
the communication cable when there is
no peculiarity with the address.
Check the communication cable and the connector
of the outdoor unit PCB, and change the PCB.
Yes
No
No
No

Samsung AM160FNBFEB/EU Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	15.88 mm
Liquid hose diameter	9.52 mm
Refrigerating medium	R410A
Air conditioner functions	Heating
Heating capacity (nominal)	54600 BTU/h
Heating capacity in watts (max)	16000 W
Cooling capacity in watts (nominal)	- W
Operating temperature (heating) (T-T)	-20 - 24 °C
AC input voltage	220-240 V
Current (heating)	14.3 A
AC input frequency	50-60 Hz
Design load (cooling)	- kW
Energy efficiency scale	A++ to G
Power consumption (heating) (max)	3100 W
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A++
Indoor unit type	Wall-mountable
Indoor unit depth	330 mm
Indoor unit width	518 mm
Indoor unit height	1210 mm
Indoor unit weight	104000 g
Indoor units quantity	1
Indoor unit package depth	426 mm
Indoor unit package width	652 mm
Indoor unit package height	1289 mm
Indoor unit package weight	107000 g
Indoor unit sound power level	42 dB
Indoor unit noise level (high speed)	60 dB
Outdoor unit noise level	- dB
