2-20 Samsung Electronics
Indoor Unit(cont.)
QWall Mounted type(Neo Forte with EEV)
Model AM022FNQDEH/TK AM028FNQDEH/TK AM036FNQDEH/TK
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP HP HP
Performance
Capacity
Cooling*
2)
kW 2.2 2.8 3.6
Btu/h 7,500 9,500 12,200
Heating*
3)
kW 2.5 3.2 4.0
Btu/h 8,500 10,900 13,600
Condensate (with High fan speed) Liters/h 1.12 1.44 1.91
Power
Input W 25
*5)
25
*5)
30
*5)
Running Current A 0.16
*5)
0.16
*5)
0.18
*5)
Sound Level Sound Pressure *
4)
dB(A) 43 44 44
Fan
Type - Crossflow fan Crossflow fan Crossflow fan
Motor
Model - YFK-8-4-SX06 YFK-8-4-SX06 YFK-8-4-SX06
Type - Feedback SSR Feedback SSR Feedback SSR
Output W - - -
Airflow Rate
Cooling (High) m
3
/min 7.80
*5)
7.80
*5)
9.30
*5)
Heating (High) m
3
/min 8.20
*5)
8.20
*5)
9.50
*5)
Refrigerant
Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom&Thermistors Micom&Thermistors Micom&Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7
Drain ø, mm ID 18 hose ID 18 hose ID 18 hose
Weight
Net Weight kg 8.3 8.3 8.3
Shipping Weight kg 11.3 11.3 11.3
Dimensions
Net Dimensions (W x H x D) mm 825x285x189 825x285x189 825x285x189
Shipping Dimensions (W x H x D) mm 900x349x252 900x349x252 900x349x252
Functions
Auto Restart - O O O
Auto Swing - O O O
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - O O O
Standard
Accessories
Installation Manual - O O O
Operation Manual - O O O
Pattern Sheet for Installation - X X X
Flexible Drain Hose - O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable)
Wireless Remote Controller ARH-5012 ARH-5012 ARH-5012
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00 MR-DH00
Wired Remote
Controller
Simplified - MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.

Samsung AM160FNBFEB/EU Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Product color	White
Gas hose diameter	15.88 mm
Liquid hose diameter	9.52 mm
Refrigerating medium	R410A
Air conditioner functions	Heating
Heating capacity (nominal)	54600 BTU/h
Heating capacity in watts (max)	16000 W
Cooling capacity in watts (nominal)	- W
Operating temperature (heating) (T-T)	-20 - 24 °C
AC input voltage	220-240 V
Current (heating)	14.3 A
AC input frequency	50-60 Hz
Design load (cooling)	- kW
Energy efficiency scale	A++ to G
Power consumption (heating) (max)	3100 W
Hourly energy consumption (cooling)	- kWh
Energy efficiency class (heating) (Average heating season)	A++
Indoor unit type	Wall-mountable
Indoor unit depth	330 mm
Indoor unit width	518 mm
Indoor unit height	1210 mm
Indoor unit weight	104000 g
Indoor units quantity	1
Indoor unit package depth	426 mm
Indoor unit package width	652 mm
Indoor unit package height	1289 mm
Indoor unit package weight	107000 g
Indoor unit sound power level	42 dB
Indoor unit noise level (high speed)	60 dB
Outdoor unit noise level	- dB
