Connecting to MDC

Using MDC via RS-232C (serial data communications standards)

An RS-232C serial cable must be connected to the serial ports on the PC and monitor.

RS232C IN RS232C OUT

DISPLAY OUT

Monitor 1

Monitor 2

Computer
