12_
connection & installation
connection & installation
Assembling Lens and Camera
y
How to connect (SHC-745)
y
Basic Wiring
y
Lens
SLA-880
SLA12240
y
y
Camera
SHC-745
SCB-3000
SCB-4000
y
y
y
PCB
How to connect (SCB-4000)
y
How to connect (SCB-3000)
y
Power module
485- 485+
Communication /
Control (485)
GND
MD
(Motion Detection)
* The power adaptor (AC) has no polarity.
Light
Projector
Power
Module
