● CONNECTION & INSTALLATION
Communication Method Settings
Select a communication method for the camera.
Function ON OFF
#5 Transfer Mode Switch RS-422(4Wire) RS-485(2Wire)
Communication Response Settings
Select a communication response method for the camera and controller: Response or No Response.
Function ON OFF
#6 Response Mode Switch Response No Response
Termination Settings
To prevent the attenuation of communication signals between the camera and controller, the items at
the end of line must be set up with the termination settings.
Camera Input Position
#7 #8
Terminal Resistance TX ON OFF
Terminal Resistance RX OFF ON
When terminating for RS-485: #8 l ON
When terminating for RS-422: #7, #8 l ON
Initialize
Initialize the system using the Initialize switch on the rear of the product.
Once initialized, all current settings will return to the factory default.
Initialize Do not use initialization
#10 ON OFF
If you do not set the Reset witch to OFF after resetting the system, all stored data will be lost when you restart the
system.
