● SETUP (SCU-VAC/VAC1)
Comm. Setting (SCU-9051)
- Parity: You can set the parity bit. (default : EVEN)
The communication settings should be confi gured in accordance with the camera specifi cation. Otherwise, the product
may not work properly.
Open Camera Menu
You can access the camera setup menu.
The OSD language of the camera setup menu does not sync with the positioning system.
The communication settings should be confi gured in accordance with the camera specifi cation. Otherwise, the product
may not work properly.
Per communication settings of the camera module
- SCU-VAC/VAC1: ID=1, baud rate =9600, communication mode= 8-N-1
- SCU-9051: ID=1, baud rate =9600, communication mode = 8-E-1
z
M
z
M
Ú This instruction applies to SCU-9051. For VAC/VAC1 camera settings, refer to each product’s
user manual.
Main Setup
Press the SET button to display the MAIN SETUP
menu screen. The MAIN SETUP menu uses a
tree structure. When you select a function, a sub
menu will appear.
z
MAIN SETUP
► 1. BRIGHTNESS AUTO
2. CONTRAST MANUAL
3. RANGE AUTO
4. NUC
5. NUC MODE INTERVAL
6. IMAGE ADJ
7. SPECIAL
8. SAVE
9. EXIT
To Next Page
